Parameters:
Voltage: 220V/110V
Power: 1500W
Temperature range: 180 ℃ -200 ℃
Time range: 0-999seconds
Coaster size: 105X230MM
Packaging size: 92X45X38CM
Weight: 32KG
Heating time: rise to 180 degrees Celsius for 3 minutes
Transferable cup diameter range: 7.5cm-9cm
Transferable cup height range: within 11.5cm
Instructions for use:
Before heat transfer, adjust the pressure according to the size of the cup (adjust the pressure adjustment nut). Plug in the power supply, and the pressure should not be too high, otherwise it may easily damage the machine.
Set the time of the toaster to 200-240 seconds; Set the temperature to 200 ℃ (The temperature control instrument has complex functions, and there is no need for additional adjustment operations besides setting the temperature value, otherwise it may cause the instrument program to be disordered and unable to work properly!)
Cut the printed paper and stick it onto the cup. Fix it slightly with high-temperature adhesive strips at both ends. Place the cup with the transfer paper on the machine, turn on the power switch, and the machine starts heating the transfer cup.
When the heating time reaches the set time, the alarm will sound, turn off the time power switch, stop for about 10 seconds, release the quick grip handle, take out the cup, and remove the transfer paper. A beautiful and personalized image cup has been made. Turn off the power switch if you don't continue printing the cup.
When this machine is not in use for a long time, it is necessary to place an empty cup and close the pressure handle to protect the baking pad
Note:
For safety reasons, the power supply must comply with a single-phase 3-wire power supply with a protective grounding wire
The pressure should not be too high, otherwise it will cause deformation of the pressure handle
The function of temperature control instruments is relatively complex, and there is no need for additional adjustment operations besides setting temperature values, otherwise it can easily cause the instrument program to be disordered and unable to work properly!!
