Product parameter
Product model:MX-210
Product Name:Household Lathe
Motor power:750W/220V
Chuck diameter:125mm
Spindle accuracy:0.01-0.03mm
Spindle taper:Morse No.3/Morse No.5
Bed width:100mm
Small carriage stroke:55mm
Turning inch threads:8-44TPI
Maximum machining diameter:130mm
Speed:low 50-1250 high 100-2500RPM
Tailstock taper:Morse No.2
Tail seat cover stroke:60mm
Spindle through hole diameter:38mm large through hole
Distance between centers:400mm
Rotation diameter:210mm
Middle carriage stroke:75mm
Turning metric thread:0.5-3mm
Lathe spindle center height:108mm
Net weight:80kg
