Name: Pneumatic steel belt baler
Applicable strap size: width: 13.16.19mm thickness: 0.5-1.5mm
Dimensions: 28(l)*16(w)*18(h)CM
Tightening force: 2800N
Tape form: friction welding
Air pressure standard: 0.5-0.8mpa
Power: 3000 watts
Applicable packing belt: plastic steel belt, PP belt
Product weight 3.8kg
Power Type: Pneumatic
installation steps
Step 1: Use a tape to wrap the bandage, hold the overlapping part with your left hand, leave about 300 at the tail, and gently pull the rest with your right hand.
Step 2: Right hand grip and retractor Insert the upper and lower parts of the strap into the baler.
Step 3: Press the tension button (right side) with your right thumb until the strap is firmly taut.
Step 4: Press the fuse button (red) with your right thumb until the strap is soldered and cut.
Step 5: Hold the handle and retractor with your right hand. Press the rewind switch with the pinky finger of the right hand until the belt is out of tension, depress the handle and retractor, and remove the baler from the belt.
